DR5347

• Length:  7.13" / 181.1 mm
• Style: PRO-H
• Bolt Size: 7/16"
• Bolt Type: WMC
• Pin Width: 1.230" / 31.24 mm Tapered
• Big Width: 1.23" / 31.24 mm
• Big Bore: 2.6905" / 68.339 mm
• Pin Bore: 1.3088
• Total Weight: 1181 grams

Carrillo offers a variety of fasteners, in various sizes, including metric and materials such as H-11 steel (WMC) and multiphase (CARR).
BOLTS

STRAIGHT H-BEAM

The stoutest beam configuration available. It is capable to handle the most abusive forces in an engine.

BUSHINGS & SPLIT BUSHING

Carrillo's bushings are generally manufactured from Aluminum/Silicon/Bronze.
As a custom connecting rod manufacturer we also offer a veriety of other material such as Nickel/Tin/Copper & Beryllium Copper

UNPRECEDENTED CONNECTING ROD MANUFACTURING

Carrillo Connecting rods were founded by Fred Carrillo in 1963. Approaching the challenges of manufacturing without compromised results, Fred knew the never ending quest for speed would require the same desire in component manufacturing.

Carrillo is focused and committed to manufacturing excellent connecting rods period. This dedication has created one of the most impressive success records of any automotive aftermarket parts supplier. Their long-lasting relationship with high-end racing teams, such as NASCAR, IndyCar, American Lemans and GrandAM, has enabled Carrillo to continually push the envelope on innovative design.

Through these relationships, they constantly introduce a wide range of catalog items showcasing the latest advancements in connecting rod technology. The Carrillo Rods quest of excellence pushes them to success, but confident use by truck owners everywhere is what keeps them moving forward.

DR5348

• Length:  7.13" / 181.1 mm
• Style: PRO-H
• Bolt Size: 7/16"
• Bolt Type: CARR
• Pin Width: 1.230" / 31.24 mm Tapered
• Big Width: 1.23" / 31.24 mm
• Big Bore: 2.6905" / 68.339 mm
• Pin Bore: 1.3088
• Total Weight: 1189 grams
